Reveals are a great way to add interesting design elements to a bare wall — they give any room in which they’re installed a sleek, modern and unique quality. Trim-Tex’s Architectural Reveal Bead creates the sharpest, cleanest aesthetic reveals in drywall you can get, with 1⁄8" of built-in expansion control.

Stock # - Size - Pieces Per Box

• AS5150 - 1/4" x 1/4" - 25
• AS5130 - 3/8" x 3/8" - 20
• AS5160 - 1/2" x 1/4" - 20
• AS5110 - 1/2" x 1/2" - 20
• AS5210 - 1/2" x 3/4" - 15
• AS5310 - 1/2" x 1" - 15
• AS5315 - 1/2" x 2" - 10
• AS5320 - 5/8" x 1/2" - 15
• AS5325 - 5/8" x 5/8" - 15
• AS5330 - 5/8" x 3/4" - 15
• AS5340 - 5/8" x 1" - 12

Features

• Create stunning reveals
• Easy to install
• Durable & resilient

Installation Guide

Architectural Reveal Bead Installation Guide-1

Reveal Radius Chart

Submittal Sheets

Architectural Reveal Bead Submittal Sheet R1

SDS

SDS - Rigid Vinyl Drywall Accessories 01Aug2018
